AL-KO

AL-KO AMS Mammut

The Mammut mover functions optimally when mounted on caravans from 2010 and onwards and also have an M punched on the chassis. There is no loss of ground clearance, which can be a big advantage for lots of caravans. A fitted Mammut M-20 only weighs 32 kg. The difference in weight becomes clear when we look at the AL-KO Vario chassis with M, where a mounting plate of 5 kg is needed to fit other movers. You need to add this to the weight of the mover.
Here at CaravanMoverShop our expert knowledge means that we recommend the AL-KO Mammut mover for caravans with less ground clearance and with the new M embossed Vario chassis. Other caravan mover models cause a loss of ground clearance of 5-6 cm (Reich/Truma) up to 9 cm (Go2 and other brands) for caravans with the Vario chassis. By comparison, the AL-KO Mammut mover's ideal suitability for caravans with the Vario M chassis means that this degree of loss of ground clearance, along with the problems associated with having little ground clearance, is avoided.


AL-KO Mammut

Control

Before you can operate the mover, you need to activate it. This is done by holding the remote control in front of the sensor. After you have done this, you can push the button that will bring the mover in position to the tires. The joystick will allow you to maneuver the caravan easily and comfortably.

Integrated (M20) or Under Chassis Fitting (S2x)

There are two Mammut models. The lower variant (model S) is to be used on chassis that do not have the punched M. You will lose around 6 cm ground clearance. The other, higher installation type M, does not lose ground clearance because it is mounted directly on the chassis beams. The engines of these models are the same, but the lower variant is 10 kg heavier. This can be converted to the higher variant for future-use.
The embossed M has been included on chassis since 2010. As previously stated, it is possible to fit the integrated version of the AL-KO Mammut mover with the advantage of no loss of ground clearance. The mover is fitted left and right with a crossbar across the chassis. Please be aware that fitting the mover is more complicated than it might first seem – if you are fitting the mover yourself make sure you read the instruction manual thoroughly and allow sufficient time to fit the mover.

Benefits of the AL-KO Mammut

The greatest advantage of the AL-KO Mammut mover is no loss of ground clearance. What also makes this mover special is the difference in its appearance. The AL-KO Mammut mover is completely encased in aluminum. It looks great and is also completely protected against water, dust, dirt and so on, with an IP65 rating. As the AL-KO Mammut mover is completely encased, you are free to clean it with water without fear of causing any damage.

Remote Control Joystick Operation

To operate the AL-KO Mammut mover the mover's remote control joystick and magnetic switch must be paired. The magnetic switch can be fixed easily and conveniently to the A-Frame at the front of the caravan, as shown in the image below.

After pairing the remote control joystick and magnetic switch, then on the remote control joystick select the automatic application of the rollers onto the caravan wheels. After this you can operate the mover with the remote control joystick, providing you with precise, variable speed control and seamless direction control.

The AL-KO Mammut mover delivers controlled and smooth start and stop functions when maneuvering your caravan. Other impressive functions include the ability to maneuver your caravan through a 360 degree turn and also to hold your caravan steady on slopes of up to 28%. The maximum speed of the AL-KO Mammut mover is 0.5 km/h (14 cm/s).


AL-KO Mammut magnetic switch

AL-KO Ranger S21
